ModelQuantumScanⅡ
Specifications
Speed : 1.1sec
Scan Area : 108(L) x 148(W) mm
Resolution : 300dpi
Color : 24 bit True Color, IR
Sensor Method : Flatbed CIS
OS : Windows 7, 8.1, 10 (32/64 bit,
WHQL certified)
ApplicationsMultifunctional Flatbed CIS ID Card &
Passport Reader
Feature
Multifunctional Flatbed CIS ID Card & Passport Reader
- Flatbed CIS technology
- High Quality 300dpi Color
- Supports Various type of illumination (White, RGB, IR)
- Readable MRZ, OCR, BARCODE
- USB 2.0 Interface
- TWAIN Compatible
- Optional Contact/Contactless SmartCard & SAM Slot
Specifications
- Active Scan Area : 108(L) x 148(W) mm
- Resolution : 300dpi
- Speed : 1.1 second
- Color : 24 bit True Color, IR Image
- File Format : BMP, JPG
- Sensor Method : Flatbed Contact Image Sensor
- S/W Interface: Supported TWAIN Driver
- Interface : USB 2.0 High Speed
- Power : AC 1000~240V 50/60Hz, 12V/3A
- Dimention : 202(W) * 170(D) * 79(H) mm
- Weight : Approx. 1.1kg
SDK
MRZ
Requirements
- OS : Windows 7, 8.1, 10 (32/64 bit, WHQL certified)
